Function Description
VKN VP1000 LED 4-in-1 Moving Head Profile empowered by a high-brightness LED engine and premium optics, the VKN VP1000 delivers powerful beams, smooth washes, and razor-sharp framing. It features a versatile 3.5 to 45 degree motorized zoom, a plus/minus 120 degree rotatable 4-blade shutter system, CMY+CTO color mixing, and rich dynamic effects (dual prisms, animation wheel, and sharp gobos). Backed by an efficient cooling system for ultimate stability, this profile is the perfect choice for professional concerts, theaters, and broadcast studios.
Technical parameters
Light Source System
- Light source: 800W LED module
- LED lifetime: >20,000 hours
- CRI: Standard mode Ra > 70 / High CRI mode Ra > 90 (switchable)
Optical System
- Zoom range: 3.5°–45° linear high-speed zoom
- Output lens diameter: 136 mm
- Illuminance: 147,000 Lux @ 5m
Color System
- CMY infinite color mixing system
- Linear CTO color temperature correction (7300K–2600K)
- Color wheel: 1 independent color wheel 7 colors + open white
- Stepped and linear color change modes, adjustable rainbow effect
Gobo system
- Rotating gobo wheel: 7 interchangeable rotating glass gobos, each with independent bi-directional rotation
- Fixed gobo wheel: 11 metal gobos + open, with variable-speed shake effect
Cutting System
- 4 independently controllable framing blades, allowing precise beam shaping and geometric pattern creation, ±120° rotation
Effect
- Animation wheel: Independent animation wheel with dynamic flame, flowing water, and other motion effects simulation
- Prism system: 1 × 4-facet prism and 1 × 4-facet linear prism, independently bi-directional rotation
- Dimmer: 0–100% smooth linear dimming
- Strobe: Electronic strobe with variable speed effects
- Frost filter: 1 independent frost filter for smooth and soft beam output
- Motorized iris: 5–100% fast linear adjustment
Pan &Tilt
- Pan 540°, Tilt 270°, auto return, 32-bit fine adjustment, with magnetic encoder system for precise positioning
Electrical & Interface
- Input voltage: AC100V–240V, 50/60Hz
- Rated power: 950W
- Signal interface: 3-pin & 5-pin XLR signal input/output
- Fuse: 250V 20A
Control & Programming
- Control channels: 39/41CH
- Control protocol: DMX512 / RDM, optional NFC and Art-Net
- Display: 2.4-inch touchscreen display with Chinese & English bilingual operating system, reversible 180° display
- Energy saving sleep mode: Automatically enters sleep mode when signal is disconnected
- Software upgrade: Firmware upgrade via DMX signal cable
- Cooling system: High-efficiency copper heat pipe cooling system, intelligent variable-speed fan, built-in temperature sensor with automatic thermal regulation
Fixture Structure
- Hosing material: Flame-retardant nylon, high-temperature resistant
- Mounting: Integrated folding omega clamp design
- Operating temperature: -20°C to 45°C
- Protection rating: IP20
Size & Weight
- Product dimensions: 38*26.9*68.4cm (L*W*H)
- Net weight: 27.5 kg
